| Frequency band | Shielding frequency | Radio frequency power | ||
| CH1 | CDMA 2G: 870-880MHz | 10W | ||
| CH2 | WCDMA3G/5G: 2110~ 2170MHz | 10W | ||
| CH3 | GSM 2G/4G: 925~ 960MHz | 10W | ||
| CH4 | LTE 4G/WiFi: 2300 ~ 2500MHz | 10W | ||
| CH5 | FDD-LTE 2G/4G: 1805~ 1875MHz | 10W | ||
| CH6 | TDD-LTE 4G: 2515 ~ 2570MHz | 10W | ||
| CH7 | TDD-LTE 4G: 1850-1920MHz | 10W | ||
| CH8 | TDD-LTE 4G: 2010-2025MHz | 10W | ||
| CH9 | 5G NSA/SA: 2570-2670MHz | 10W | ||
| CH10 | 5G NR: 3400-3600MHz | 5W | ||
| CH11 | 5G SA: 750-790MHz | 10W | ||
| CH12 | WiFi: 5150-5850MHz | 2W | ||
| Main engine size | 560×302×200 mm（Length × width × height） | |||
| Antenna size | 450x270x45 mm（Built-in directional antenna） | |||
| Package size | 610×312×210mm | |||
| Machine weight | 12Kg | |||
| Ambient temperature | -20℃ ~ 55℃ | |||
| Relative humidity | ≤85%RH | |||
| Antenna parameter | Directional antenna, gain 5dBi, standing wave ratio ≤1.5 | |||
| Power supply | 320W | |||
| Power input | AC: 110-240V | |||
| On-off control | There is no | |||
| Shell material | Aluminum alloy metal shell with PPC panel, 5mm thick | |||
Aisenton Technology has a strong research and development team, a first-class technology research and development team, rich design and practical experience, committed to the research and development and manufacture of communication security protection equipment, is the global anti-terrorism and explosion-proof equipment supplier, the initiator and leader of new security and new communication, and contributes to the global security protection.
