Electrical Specifications
Frequency Range 806- 960&1710-2700MHz
VSWR < 1.4
Gain 9/11dBidBi
Horizontal 3dB Beamwidth 90°
Vertical 3dB Beamwidth 50° TR>
Polarization Type: Vertical or horizontal
Impedance: 50Ω
Maximum Input Power: 100 W
Connector: N-Female
IM.3rd Order (2*43dBm): <-150dBc
Lightning Protection: Direct Ground
Mechanical Specifications
Dimensions: 295*210*65mm
Weight of Antenna: 0.8kg
Radome Material: ABS
